◆FDD系列是一款专用型的滑动开关，也叫推拉开关或推拨开关，应用于各类电动工具和园林工具，如：电木铣、吹吸机等。
◆FDD series are special type slide switches, for used in power-tools or gardening tools such as Routers, Blowers, etc.
产品特征Features
◆可选带两种不同金属外壳 Optional with different shell
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max.Inrush current at 250V48A
→最大冲击电流 Max.Inrush current at 125V48A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
